Bosch Power Max Level 2 User Manual

en
|
6
|
Installation and Operating Instructions
|
Power Max Level 2 Charging Station
569217 | REV. A | 05.22.2013
Bosch Automotive Service Solutions
4.4 Installing the Power Max Level 2 Charging Station
1. SeeFigure4-1.SecuretheLevel2ChargingStationmountingbrackettothewallusingappropriatescrewsand
bracketholes,asshowninFigure4-1.Thread1/4-in.expansionboltsthroughbracketoffsetholesintomasonry
wallsasshownandtorqueto78lb·in(8.8N·m).Thread2-in.,orlonger,No.8woodscrewsthroughbracket
inlineholesintonishedwallssupportedbywoodstudsandtorqueto26lb·in(3N·m).
Note:
TheLevel2ChargingStationmustbemountedatasufcientheightfromgradesuchthattheheightoftheplug
dockislocatedbetween24–48in.(0.6–1.2m)fromgradeperNECArticle625.
Figure4-1.Mountingbracketuseonmasonrywall(left)andnishedwall(right)
2. SeeFigure4-2.Chooseappropriateconduitinaccordancewithallapplicablestate,local,andnationalelectrical
codesandstandards.UseexibleconduitwhenconnectingtotherearoftheLevel2Chargingstationto
faciliaterotationandinstallationonmountingbracket(Figure4-4).
1
2
1. Flexible conduit
2. Rigid conduit
Figure4-2.Conduituse
