Power Max Level 2 Charging Station | 11
|
en
6 Operations and Troubleshooting
6.1 Charging
1. SeeFigure6-1.TurnthePowerMaxLevel2ChargingStationpowerswitchtoON.Wait3secondsforthegreen
indicator light.
Figure6-1.PoweringonthePowerMaxLevel2ChargingStationandremovingthechargingplug
2. See Figure 6-2. Release the charging plug from the plug dock and connect it to the EV to start the charging
process.
Figure 6-2. Connecting the charging plug to the EV
