Bosch Power Max Level 2 User Manual

en
|
2
|
Installation and Operating Instructions
|
Power Max Level 2 Charging Station
569217 | REV. A | 05.22.2013
Bosch Automotive Service Solutions
1 Introduction
TheBoschPowerMaxLevel2ChargingStationisdesignedfortheU.S.markettochargeplug-inelectricvehicles
(PHEV) and battery electric vehicles (BEV). It provides AC Level 2 Charging that effectively shortens charging time
for typical electric vehicles (EVs) when compared to the Level 1 Cordset.
1.1 Applications
} Residential
} Private and public parking facilities
} Fleet
} Shopping malls and retailers
} Workplace
Please read and follow these safety warnings and operating instructions carefully before operating the Bosch Power
MaxLevel2ChargingStation.Failuretofollowtheseinstructionsmayresultinseriousinjuryorpropertydamage.
2 Important Safety Warnings and Instructions
IMPORTANT SAFETY INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
WARNING
Disconnect electrical power to the Power Max Level 2 Charging Station before installation. Failure to do
so may cause physical injury or damage to the electrical system and charging unit.
CAUTION
 Toreducetheriskofre,connectonlytoacircuitprovidedwith20amperes(EL-51245)or40amperes
(EL-51253,EL-51254)maximumbranchcircuitovercurrentprotectioninaccordancewiththeNational
ElectricalCode,ANSI/NFPA70.
} Read all the instructions before using this product.
} Children should be supervised when this product is used around children.
} DonotputngersintotheEVconnector.
} Do not use this product if the EV cable is frayed, has broken insulation, or displays any other indication of
damage.
} Do not use this product if the enclosure or the EV connector is broken, cracked, open, or show any other
indication of damage.
} Thisproductshouldbeinstalledonlybyaqualiedapprovedtechnician.
} Makesurethatthematerialsusedandtheinstallationproceduresfollowlocalbuildingcodesandsafety
standards.
} The information provided in this manual in no way exempts the user of responsibility to follow all applicable
codes or safety standards.
} Boschisnotresponsibleforphysicalinjury,damagetopropertyorequipmentcausedbytheinstallationofthis
product.
} Thisdocumentprovidesinstructionsforthewall-mountedPowerMaxLevel2ChargingStationandshouldnotbe
used for any other product. Before installation or use of this product, you should review this manual carefully and
consult with a licensed contractor, licensed electrician, or trained installation expert to make sure of compliance
with local building codes and safety standards.

Bosch Power Max Level 2 Specifications

General

Brand	Bosch
Model	Power Max Level 2
Category	Battery Charger
Language	English
