5 Transport and storage
5 Transport and storage
For storing and transporting the product
always observe the ambient conditions
specified in the technical data (see
“Technical data” on page 27).
6 Assembly
When installing the product always observe
the ambient conditions specified in the
technical data (see “Technical data” on
page 27).
Required tools
• Screwdriver for spring-type terminal
Assembling the IM24V
1. Always switch off the power supply to the
relevant system component before
assembling the IM24V interface module.
2. Insert the IM24V interface module into
the appropriate slot on the system
component (B1 or B2) until it catches
(example in Fig. 6).
3. Tighten the front knurled bolts until the
front panel fits tightly.
CAUTION
Risk of injuries and damage
to property!
Assembly of the IM24V interface
module requires basic mechanical
and electrical knowledge.
y Only qualified personnel are
authorized to assemble the
IM24V interface module (see
“Personnel qualifications” on
page 17).
y Measures to prevent
electrostatic discharge (ESD
protection) must be
undertaken to protect the
module and system
components during all
assembly work.
CAUTION
Risk of injuries when
assembling under voltage!
If you do not switch off the power
supply before assembling the
IM24V interface module, you may
get injured or the device or system
components may be damaged.
y Always switch off the power
supply to the relevant system
component before assembling
the IM24V interface module.
