3 Ratings and Dimensions
UL Ratings and Dimensions
Description Symbol Unit
HCS02.1E-
W0012-_-03
HCS02.1E-
W0028-_-03
HCS02.1E-
W0054-_-03
HCS02.1E-
W0070-_-03
Listing according to UL standard
(UL)
UL 508 C
Listing according to CSA standard
(UL)
Canadian National Standard(s) C22.2 No. 14-10
UL files (UL) E 134201
Pollution degree (UL) 2
Ambient temperature with nominal
data (UL)
T
amax
°C 40
Ambient temperature with reduced
nominal data (UL)
T
amax_red
°C 55
Mass m kg 2,90 3,80 6,70 6,80
Device height (UL)
1)
H mm 290 352
Device depth (UL)
2)
T mm 206
Device width (UL)
3)
B mm 65 105
Minimum distance on the top of
the device
4)
d
top
mm 80
Minimum distance on the bottom
of the device
5)
d
bot
mm 80
Horizontal spacing on the device
6)
d
hor
mm 5
Rated control voltage input (UL)
7)
U
N3
V 24 ± 20 %
Rated power consumption control
voltage input at U
N3
(UL)
8)
P
N3
W 12 14 23
Short circuit current rating (UL) SCCR A rms 42000
Rated input voltage, power (UL)
9)
U
LN_nenn
V 3 x AC 200...500
Tolerance rated input voltage (UL) % ± 10
Input frequency (UL)
f
LN
Hz 50...60
Tolerance input frequency (UL) Hz ± 2
Rated input current (UL)
I
LN
A 6,0 13,0 20,0 30,0
Branch circuit protection fuse
(UL)
10)
20 25 40
Required wire size according to
EN 60204‑1
11)
A
LN
mm
2
1,5 4 6
Required wire size according to
UL 508 A (internal wiring); (UL)
12)
A
LN
AWG AWG 14 AWG 12 AWG 10
Last modification: 2010-08-04
DOK-INDRV*-HCS02******-IT01-EN-P
Rexroth IndraDrive Drive Controllers Power Sections HCS02
Bosch Rexroth AG 23/67
Ratings and Dimensions
