48/78 About these products
Bosch Rexroth AG, Control block SB24/34, RE 66170-B/2019-05-15
5.4.2 Examples for control blocks with connecting plate or end valve
Mechanical control block
with EVL
Mechanical control block
with EHR24-EM2 EVL
EHS control block
with EVL
EHS control block
with EHR24-EHS with EVL
Mechanical control block with EHR-EM2, ZAP, CVL and EVL EHS control block with EHR-EHS, ZAP, CVL and EVL
Mixed control block with SB24-M, SB24/SB34-EHS,
EHR-EM2 and SB24-M EVL
Mixed control block with SB24-M, EHR-EM2, ZAP,
SB24-M EVL and SB34-EHS CVL
For detailed combination options of the individual control block segments, refer
to chapter5.5 "Combination options" on page49.
