3.3 Connections, controls and displays
4
5
6
1 2 3
7
8
9
5
8
1 SSD activity (orange) 6 Ethernet
2 Power indicator (blue) 7 Dual USB 3.0
3 Power switch 8 2x DisplayPort (via USB-C)
4 DC power connector 9 Kensington lock
5 2x HDMI
