Key to symbols and safety instructions
Greenstar Danesmoor Utility
2022+
and Utility System
2022+
- 6 721 846 263 (2022/01) 3
1 Key to symbols and safety instructions
1.1 Key to symbols
Warnings
The following keywords are defined and can be used in this document:
• NOTICE indicates a situation that could result in damage to property
or equipment.
• CAUTION indicates a situation that could result in minor to medium
injury.
• WARNING indicates a situation that could result in severe injury or
death.
• DANGER indicates a situation that will result in severe injury or
death.
Important information
Additional symbols
Examples of additional symbols used
A numbered step in an action sequence
A sequence of numbered steps or actions carried out in a specific order
to complete a task.
1. First action
2. Second action
3. Third action
etc.
A step in an action sequence
A sequence of defined actions or steps carried out in order to complete
a task.
▶Action
▶Next action
▶etc
A reference to a related part in the document or to other related
documents.
To refer the reader to a specific figure/table/section within the manual.
e.g. figure 1.
A reference number to identify or refer to a part or item.
In a related figure, items or parts identified by a sequential number.
List entries, first and second levels
• A single component/item
• A component/list, made up of multiple parts/items.
– Sub component or sublist of main component/list.
–etc.
Abbreviations used in this manual
Read these instructions before starting any installation
These instructions are applicable to the Worcester appliance model(s)
stated on the front cover of this manual only and must not be used with
any other make or model of appliance.
The instructions apply in the UK and Eire only and must be followed
except for any statutory obligation.
This appliance must be installed by a competent person, failure to install
correctly could lead to prosecution.
1.2 General safety instructions
These installation instructions are intended for heating engineers,
plumbers, and electricians.
▶ Read any installation instructions (boiler, heating controls, etc.)
carefully before starting the installation.
▶ Observe the safety instructions and warnings.
▶ Observe national and regional regulations, technical rules and
guidelines.
▶ Record all work carried out.
Oil fumes or leaks from the appliance
If you smell oil fumes, observe the following rules.
▶ Extinguish any naked flames
▶ Isolate the electrical supply
▶ Isolate the fuel supply to the boiler
▶ Open windows and doors
▶ Rectify the fault
Health and safety
The appliance contains no asbestos and no substances have been used
in the construction process that contravene the COSHH Regulations
(Control of Substances Hazardous to Health Regulations). Where
applicable, the CE mark indicates compliance with relative EU
Directives.
Warnings in this document are identified by a warning
triangle printed against a grey background.
Keywords at the start of a warning indicate the type and
seriousness of the ensuing risk if measures to prevent
the risk are not taken.
This symbol indicates important information where
there is no risk to people or property.
Symbol Meaning
a numbered step in an action sequence
a step in an action sequence
a reference to a related part in the document or to other
related documents
a reference number to identify or refer to a part or item
a list entry
a list entry (second level)
Table 1 Symbols
ØDiameter
CH Central Heating
DHW Domestic Hot Water
DCW Domestic Cold water
HE Heat Exchanger
TRV Thermostatic Radiator Valve
IP Ingress Protection
CF Conventional Flue
RS Room sealed
N/A Not Allowed
SEDBUK Seasonal Efficiency of Domestic Boilers in the UK
OFTEC Oil Firing Technical Association for the Petroleum Industry
WRAS Water Regulations Advisory Scheme
IET Institute of Engineering and Technology
LABC Local Authority Building Control Body
DWTA Domestic Water Treatment Association
