6 | Boiler information AU/NZ
6 720 646 195a (2010/11)
2 Boiler information
2.1 Boiler
Fig. 1 Boiler carton contents
Standard package:
1 Hydronic system boiler 5 Fascia panel
2 Wall mounting frame 6Syphon assembly
3 Hardware literature pack (see checklist) 7 Metric to Imperial adapter pack
4 Bottom panel
2
4
3
5
* 710mm to top of case front
1
700mm*
400mm
330mm
Depth to wall
(When tted to wall frame)
6
6720646195-01.1Wo
7
