Item

Number

Description Part

Number

Note

1 Assy, Base Top Comp. 189092

2 Assy, Base Center Comp. 189108

3 Assy, Bracket CD-CH Comp. 189159

4 Assy, Chassis CD Comp. 189199

5 Assy, Base Rear Comp. 189155

6 Assy, Shaft EV Comp. 189160

7 Assy, Base Front Comp. 189193

8 Assy, Frame EV Comp. 189149

9 Assy, Base Side Comp. 189112

10 Assy, Chassis Mount Comp. 189157

11 Assy, Bracket Loading Comp. 189156

A1 FPC PIC 189154

A104 Assy, FPC Elevator 189161

A153 FPC Lift 189153

A228 Spring Tension DL 189144

A232 FPC Loading 189152

CN906 Wire Assy, 8P, 555mm 189162 2

- Assy, PCB-W, Main 189163 1

Note: 1. This is the complete CD changer mechanism PCB.

2. This part is connected to the CD changer mechanism's PCB.

Note: The table above lists all the parts that are available for the CD changer mechanism

portion of the CD-20. The part numbers that are not proceeded by a letter represent an assem-

bly that is outlined in Figure 8. Part numbers that are preceded by a letter represent individual

parts called out in Figure 8.

CD MECHANISM PART LIST

(Refer to Figure 8)
