Bose CD-20 User Manual

4
SPECIFICATIONS
Physical
Dimensions: 2.6"H x 15.5"W x 8"D
(6.6 x 39.4 x 20.3 cm)
Weight: 5.9 lbs. (2.7kg)
Top Cover: Brushed aluminum finish
Bottom Cover: Plastic, Black
Display: Vacuum fluorescent
Power Input: 5mm coaxial power jack Detachable power-pack,
12VAC, 1.6A
Line Level Inputs: Tape, Aux, Video 1, Video 2 RCA Jack pairs
Right=Red, Left=White
Line Level Outputs: Tape RCA Jack pair
Right=Red, Left=White
Zone 1: Miniature 8-pin DIN connector L/R fixed line level audio, L/R
variable line level audio, DC
turn on signal, speaker com-
mand data out, audio ground,
and data ground
Zone 2: Miniature 8-pin DIN connector L/R fixed line level audio, L/R
variable line level audio, DC
turn on signal, speaker com-
mand data out, audio ground,
and data ground
Serial Data Port: 3.5mm miniature stereo jack data out, data in, and ground
Antenna Input: AM 2.5mm mono jack
FM, 75Ω USA/CSA "F" type
EURO "PAL" type
JAPAN "F" type
Headphone Connector: 3.5mm stereo jack Variable level output
FM Tuner (per IHF-T-200)
Channel Spacing: US: 200 kHz
EURO: 50 kHz
JAPAN: 100 kHz
Band Limits: US: 87.5 MHz-107.9 MHz
EURO: 87.50 MHz- 108.00 MHz
JAPAN: 76.00 MHz-90.00 MHz
De-emphasis: U.S./ Military version: 75µs
EURO version: 50µs
JAPAN version: 50µs
Usable Sensitivity: US: 12 dBf nominal/ 17 dBf limit
EURO: 17 dBf nominal/ 22 dBf limit
JAPAN: 12 dBf nominal/ 17 dBf limit
