ELECTRICAL PART LIST
Resistors (continued)
Reference Designator Description Part Number Note
R456 511 OHM, 0805, 1/10W, 1% 133625-5110
R457 511 OHM, 0805, 1/10W, 1% 133625-5110
R458 511 OHM, 0805, 1/10W, 1% 133625-5110
R459 511 OHM, 0805, 1/10W, 1% 133625-5110
R460 511 OHM, 0805, 1/10W, 1% 133625-5110
R461 511 OHM, 0805, 1/10W, 1% 133625-5110
R462 511 OHM, 0805, 1/10W, 1% 133625-5110
R463 511 OHM, 0805, 1/10W, 1% 133625-5110
R464 511 OHM, 0805, 1/10W, 1% 133625-5110
R465 511 OHM, 0805, 1/10W, 1% 133625-5110
R466 511 OHM, 0805, 1/10W, 1% 133625-5110
R467 511 OHM, 0805, 1/10W, 1% 133625-5110
R468 511 OHM, 0805, 1/10W, 1% 133625-5110
R469 511 OHM, 0805, 1/10W, 1% 133625-5110
R470 511 OHM, 0805, 1/10W, 1% 133625-5110
R471 511 OHM, 0805, 1/10W, 1% 133625-5110
R472 511 OHM, 0805, 1/10W, 1% 133625-5110
R473 511 OHM, 0805, 1/10W, 1% 133625-5110
R474 511 OHM, 0805, 1/10W, 1% 133625-5110
R475 511 OHM, 0805, 1/10W, 1% 133625-5110
R476 1.00K, 0805, 1/10W, 5% 133626-1025
R477 1.00K, 0805, 1/10W, 5% 133626-1025
R500 1.00K, 0805, 1/10W, 1% 133625-1001
R501 1 MEG, 0805, 1/10W, 5% 133626-1055
R502 1.00K, 0805, 1/10W, 1% 133625-1001
R503 1 MEG, 0805, 1/10W, 5% 133626-1055
R504 100K, 0805, 1/10W, 1% 133625-1003
R505 100K, 0805, 1/10W, 1% 133625-1003
R700 43.2K, 0805, 1/10W, 1% 133625-4322
R701 43.2K, 0805, 1/10W, 1% 133625-4322
R702 43.2K, 0805, 1/10W, 1% 133625-4322
R703 43.2K, 0805, 1/10W, 1% 133625-4322
R704 43.2K, 0805, 1/10W, 1% 133625-4322
R705 43.2K, 0805, 1/10W, 1% 133625-4322
W300 JUMPER, CHIP, 0805 133627
Capacitors
Reference Designator Description Part Number Note
C1 .01uF, 100V, 20% 180630-103
C2 .01uF, 0805, X7R, 50V, 10% 133623-103
C3 470uF, EL, 85°C, 25V, 20% 149948-471E
C4 .047uF, 0805, Z5U, 20% 148779-473
C5 .01uF, 0805, X7R, 50V, 10% 133623-103
C6 470uF, EL, 85°C, 25V, 20% 149948-471E
C7 10uF, EL, 85°C, 25V, 20% 149947-100E
C8 .01uF, 0805, X7R, 50V, 10% 133623-103
C10 2200uF, EL, 85°C, 25V, 20% 185929-222E
C11 .01uF, 0805, X7R, 50V, 10% 133623-103
C12 .047uF, 0805, Z5U, 20% 148779-473
C13 .01uF, 0805, X7R, 50V, 10% 133623-103
C14 47uF, EL, 85°C, 25V, 20% 149948-470E
C15 100uF, EL, 85°C, 50V, 20% 149948-101H 6
C15 470uF, EL, 85°C, 25V, 20% 149948-471E
