Bose ControlSpace ESP-88 User Manual

33
ELECTRICAL PART LIST
Resistors (continued)
ESP-88 Chassis 4x4 PCB Assembly
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
R738 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R740 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R741 330 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07330R 4
R742 330 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07330R 4
Resistor Arrays
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
RA550 10K, 10 PIN, 8R, 5% Yageo YC158TJR-0710K 4
RA700 33 OHM, 8 PIN, 1/16W, 5% Yageo YC164-JR-0733R 4
RA701 33 OHM, 8 PIN, 1/16W, 5% Yageo YC164-JR-0733R 4
RA702 33 OHM, 8 PIN, 1/16W, 5% Yageo YC164-JR-0733R 4
RA703 33 OHM, 8 PIN, 1/16W, 5% Yageo YC164-JR-0733R 4
RA704 33 OHM, 8 PIN, 1/16W, 5% Yageo YC164-JR-0733R 4
RA705 33 OHM, 8 PIN, 1/16W, 5% Yageo YC164-JR-0733R 4
RA706 10K, 10 PIN, 8R, 5% Yageo YC158TJR-0710K 4
Capacitors
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
C100 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C101 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C102 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C103 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C104 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C105 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C108 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C109 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C110 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C111 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C112 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C113 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C114 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C115 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C116 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C117 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C118 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C119 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C120 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C121 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C122 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C123 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C124 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C125 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C126 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C127 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C128 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
