ELECTRICAL PART LIST
ESP-88 Chassis 4x4 PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
C129 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C130 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C131 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C132 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C133 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C134 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C135 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C136 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C139 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C140 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C141 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C142 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C143 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C144 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C145 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C146 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C147 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C148 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C149 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C200 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C201 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C202 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C203 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C204 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C205 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C208 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C209 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C210 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C211 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C212 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C213 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C214 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C215 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C216 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C217 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C218 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C219 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C220 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C221 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C222 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C223 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C224 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C225 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C226 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C227 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C228 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C229 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
