ELECTRICAL PART LIST
ESP-88 Chassis 4x4 PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
C230 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C231 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C232 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C233 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C234 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C235 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C236 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C239 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C240 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C241 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C242 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C243 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C244 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C245 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C246 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C247 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C248 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C249 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C300 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C301 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C302 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C303 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C304 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C305 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C306 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C307 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C308 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C309 0.01uF, 0603, X7R, 50V, 10% Samsung CL10B103KBNC 4
C310 0.01uF, 0603, X7R, 50V, 10% Samsung CL10B103KBNC 4
C311 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C312 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C313 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C314 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C315 22pF, 0603, NPO, 50V, 5% Samsung CL10C220JBNC 4
C316 22pF, 0603, NPO, 50V, 5% Samsung CL10C220JBNC 4
C317 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C318 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C319 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C320 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C321 2700pF, 0603, X7R, 50V, 10% Samsung CL10B272KBNC 4
C322 6800pF, 0603, X7R, 50V, 10% Samsung CL10B682KBNC 4
C323 470pF, 0603, X7R, 50V, 10% Samsung CL10B471KBNC 4
C324 1500pF, 0603, X7R, 50V, 10% Samsung CL10B152KBNC 4
C325 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C326 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C327 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C328 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
