ELECTRICAL PART LIST
ESP-88 Chassis 4x4 PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
C329 0.01uF, 0603, X7R, 50V, 10% Samsung CL10B103KBNC 4
C330 0.01uF, 0603, X7R, 50V, 10% Samsung CL10B103KBNC 4
C331 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C332 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C333 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C334 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C335 22pF, 0603, NPO, 50V, 5% Samsung CL10C220JBNC 4
C336 22pF, 0603, NPO, 50V, 5% Samsung CL10C220JBNC 4
C337 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C338 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C339 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C340 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C341 2700pF, 0603, X7R, 50V, 10% Samsung CL10B272KBNC 4
C342 6800pF, 0603, X7R, 50V, 10% Samsung CL10B682KBNC 4
C343 470pF, 0603, X7R, 50V, 10% Samsung CL10B471KBNC 4
C344 1500pF, 0603, X7R, 50V, 10% Samsung CL10B152KBNC 4
C345 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C350 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C351 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C400 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C401 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C402 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C403 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C404 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C405 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C406 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C407 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
C408 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C409 0.01uF, 0603, X7R, 50V, 10% Samsung CL10B103KBNC 4
C410 0.01uF, 0603, X7R, 50V, 10% Samsung CL10B103KBNC 4
C411 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C412 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C413 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C414 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C415 22pF, 0603, NPO, 50V, 5% Samsung CL10C220JBNC 4
C416 22pF, 0603, NPO, 50V, 5% Samsung CL10C220JBNC 4
C417 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C418 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C419 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C420 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C421 2700pF, 0603, X7R, 50V, 10% Samsung CL10B272KBNC 4
C422 6800pF, 0603, X7R, 50V, 10% Samsung CL10B682KBNC 4
C423 470pF, 0603, X7R, 50V, 10% Samsung CL10B471KBNC 4
C424 1500pF, 0603, X7R, 50V, 10% Samsung CL10B152KBNC 4
C425 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C426 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C427 10uF, BI-POLAR, 16V, 40C, 20% ELNA RVB16V100M-R 4
