ELECTRICAL PART LIST
ESP-88 Chassis 4x4 PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
C428 100pF, 0603, NPO, 50V, 5% Samsung CL10C101JBNC 4
C429 0.01uF, 0603, X7R, 50V, 10% Samsung CL10B103KBNC 4
C430 0.01uF, 0603, X7R, 50V, 10% Samsung CL10B103KBNC 4
C431 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C432 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C433 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C434 220pF, 0603, X7R, 50V, 10% Samsung CL10B221KBNC 4
C435 22pF, 0603, NPO, 50V, 5% Samsung CL10C220JBNC 4
C436 22pF, 0603, NPO, 50V, 5% Samsung CL10C220JBNC 4
C437 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C438 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C439 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C440 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C441 2700pF, 0603, X7R, 50V, 10% Samsung CL10B272KBNC 4
C442 6800pF, 0603, X7R, 50V, 10% Samsung CL10B682KBNC 4
C443 470pF, 0603, X7R, 50V, 10% Samsung CL10B471KBNC 4
C444 1500pF, 0603, X7R, 50V, 10% Samsung CL10B152KBNC 4
C445 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C450 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C451 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C500 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C501 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C502 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C503 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C504 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C505 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C506 560pF, 0603, X7R, 50V, 10% Samsung CL10B561KBNC 4
C507 560pF, 0603, X7R, 50V, 10% Samsung CL10B561KBNC 4
C508 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C509 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C510 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C511 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C512 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C513 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C514 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C515 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C516 560pF, 0603, X7R, 50V, 10% Samsung CL10B561KBNC 4
C517 560pF, 0603, X7R, 50V, 10% Samsung CL10B561KBNC 4
C518 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C519 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C520 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C521 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C522 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C523 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C524 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C525 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C526 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
