ELECTRICAL PART LIST
ESP-88 Chassis 4x4 PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
C527 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C528 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C529 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C550 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C551 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C552 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C553 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C554 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C555 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C556 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C557 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C558 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C559 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C560 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C561 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C562 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C563 47uF, ELEC, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C564 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C565 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C566 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C567 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C568 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C569 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C570 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C571 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C572 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C573 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C700 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C701 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C702 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C703 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C704 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C705 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C706 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C707 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C708 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C709 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C710 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C711 12pF, 0603, NPO, 50V, 5% Samsung CL10C120JBNC 4
C712 12pF, 0603, NPO, 50V, 5% Samsung CL10C120JBNC 4
C713 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C714 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C715 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C716 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C717 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C718 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C719 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
