ELECTRICAL PART LIST
ESP-88 Chassis 4x4 PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
C720 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C721 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C722 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
C723 47pF, 0603, NPO, 50V, 5% Samsung CL10C470JBNC 4
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
L100 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L101 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L102 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L103 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L104 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L105 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L200 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L201 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L202 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L203 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L204 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L205 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
Inductors
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
D100 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D101 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D102 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D103 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D200 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D201 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D202 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D203 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D300 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D301 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D302 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D303 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D400 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D401 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D402 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D403 DIODE, SWITCHING, SC-59 Rohm DAN217 4
D700 RECT, 400V, 1A, SOD-106 Rohm 1SR154-400 4
D701 RECT, 400V, 1A, SOD-106 Rohm 1SR154-400 4
Diodes
