ELECTRICAL PART LIST
ESP-88 Digital Signal Processor (DSP) PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Vendor Part Number Note
C507 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC 4
C531 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC 4
C532 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC 4
C533 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC 4
C534 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC 4
C535 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C536 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C537 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C538 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C539 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C540 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
Inductors
Reference
Designator
Description Vendor Vendor Part Number Note
L100 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L300 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L301 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L302 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L400 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L401 XFMR, 10BASE-T, SOIC-16 E&E 821-M0542 4
L402 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L403 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L404 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L405 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L450 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L451 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L452 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L453 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L454 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L455 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D 4
L456 POWER IND, 5.2uH, 30% SUMIDA CDRH104R-5R2NC 4
L457 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
L458 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D 4
Diodes
Reference
Designator
Description Vendor Vendor Part Number Note
D450 SCHOTTKY, SC59 Toshiba 1SS396 4
D451 SCHOTTKY, SC59 Toshiba 1SS396 4
D453 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400 4
D454 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400 4
D455 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400 4
D456 SCHOTTKY, SC59 Toshiba 1SS396 4
D457 SCHOTTKY, SC59 Toshiba 1SS396 4
D458 SCHOTTKY, SC59 Toshiba 1SS396 4
D459 SCHOTTKY, SC59 Toshiba 1SS396 4
D461 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400 4
D462 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400 4
D463 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400 4
