Bose ControlSpace ESP-88 - Page 52

52
Reference
Designator
Description Vendor Vendor Part Number Note
Q450 PNP, 50V, 100Ma, SOT-23 KEC KRA102S 4
Q451 PNP, 50V, 100Ma, SOT-23 KEC KRA102S 4
Q452 PNP, 50V, 100Ma, SOT-23 KEC KRA102S 4
Q453 PNP, 50V, 100Ma, SOT-23 KEC KRA102S 4
Q454 PNP, 50V, 100Ma, SOT-23 KEC KRA102S 4
Q455 PNP, 50V, 100Ma, SOT-23 KEC KRA102S 4
Q456 PNP, 50V, 100Ma, SOT-23 KEC KRA102S 4
Q457 PNP, 50V, 100Ma, SOT-23 KEC KRA102S 4
Q458 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
ELECTRICAL PART LIST
ESP-88 Digital Signal Processor (DSP) PCB Assembly
Transistors
Integrated Circuits
Reference
Designator
Description Vendor Vendor Part Number Note
M100 SDRAM, TSOP-54 ELPIDA EDS1216AATA-75 4
M101 DSP, QFP-208 TI TMS320C6713BPYP 4
M200 PROG GATE ARRAY, QFP-208 XILINX XC2S150E6PQ208C 4
M201 OCTAL BUFFER DR, TSSOP20 ONSemi MC74VHC541DT 4
M202 OCTAL BUFFER DR, TSSOP20 ONSemi MC74VHC541DT 4
M300 MICROPROCESSOR, QFP-176 Renases HD6417706F133 4
M301 SDRAM, TSOP-54 ELPIDA EDS1216AATA-75 4
M302 FLASH MEMORY, TSOP-48 SPANSION S29GL064M90TAIR 4
M400 HEX INVERTER, TSSOP-14 ONSEMI MC74VHC04DT 4
M401 ETHER LAN CONT, TQFP-100 Cirrus CS8900A-CQ3 4
M450 TRANSCEIVER, SOIC-16 Harris/Intersil HIN202ECB 4
M452 OCTAL BUFFER DR, TSSOP20 ONSemi MC74VHC541DT 4
M453 VOLT DET, SOT-23-5 SEIKO S-80947CNMC-G9H-T2 4
M454 VOLT DET, TSOP-5 ONSEMI NCP303LSN11T1 4
M455 VOLT DET, SOT-23-5 SEIKO S-80917CNMC-G8M-T2 4
M456 VOLT DET, SOT-23-5 SEIKO S-80917CNMC-G8M-T2 4
M457 VOLT DET, Vd=3.0V SEIKO S-80930CNMC-G80-T2 4
M458 VOLT DET, SOT-23-5 SEIKO S-80940CNMC-G9A-T2 4
M460 REG, 3.3V, 1A, TO-252 NEC UPC2933T 4
M461 REG, SOT-223, TI NEC LM317DCY 4
M462 REG, SOT-223, TI NEC LM317DCY 4
M463 PWM SWITCHER TI TPS54312PWP 4
Miscellaneous
Reference
Designator
Description Vendor Vendor Part Number Note
CN452 CONN, SMT, 1.0MM, 100 PIN KEL 87BFN-100R 4
CN530 CONN, SMT, 100P Molex 52584-1079 4
X200 50.000MHz, 100ppm, 50pF KDS DSO531SVL 50MHz 4
X201 24.576MHz, 100ppm, 50pF KDS DSO531SVL
24.576MHz
4
