ELECTRICAL PART LIST

ESP-88 General Input/Output (GIO) PCB Assembly

Resistors

Reference

Designator

Description Vendor Vendor Part

Number

Note

R100 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R101 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R102 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R103 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R104 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R105 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R106 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R107 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R108 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4

R109 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4

R110 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4

R111 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4

R112 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4

R113 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4

R114 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4

R115 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4

R116 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R117 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R118 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R119 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R120 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R121 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R122 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R123 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R125 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R126 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R129 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4

R130 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4

R132 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R133 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R134 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4

R135 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R136 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R137 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R138 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R139 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R140 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R141 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R142 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4

R144 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4

R145 330 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07330R 4

R146 330 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07330R 4
