ELECTRICAL PART LIST
ESP-88 General Input/Output (GIO) PCB Assembly
Capacitors
Reference
Designator
Description Vendor Vendor Part
Number
Note
C100 10uF, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C101 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4
C102 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4
C103 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4
C104 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4
C105 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4
C106 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4
C107 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4
C108 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4
C109 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C110 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C111 10uF, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C112 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C113 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C114 10uF, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C115 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C116 12pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C120JBNC 4
C117 12pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C120JBNC 4
C118 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C119 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C120 47uF, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C121 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C122 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C123 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C124 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C125 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C126 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C127 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C128 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C129 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C130 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4
C131 47pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C470JBNC 4
C132 47pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C470JBNC 4
C403 1000pF, CER, Y5P, 2KV, 55C,
10%
Panasonic ECKD3D102KBP 4
