Bose ControlSpace ESP-88 - Page 55

55
ELECTRICAL PART LIST
ESP-88 General Input/Output (GIO) PCB Assembly
Inductors
Reference
Designator
Description Vendor Vendor Part
Number
Note
L100 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L101 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L102 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L103 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L104 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L105 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L106 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L107 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L108 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L109 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L110 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L111 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L112 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L113 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L114 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L115 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L116 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L117 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
L118 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D 4
Diodes
Transistors
Reference
Designator
Description Vendor Vendor Part
Number
Note
D108 RECTIFIER, 400V, 1A, SOD-106 ROHM 1SR154-400 4
D464 LED, RIGHT ANGLE, RED/GREEN KINGBRIGHT W42WUM/EGW 4
D465 LED, RIGHT ANGLE, RED/GREEN KINGBRIGHT W42WUM/EGW 4
D466 LED, RIGHT ANGLE, RED/GREEN KINGBRIGHT W42WUM/EGW 4
D467 LED, RIGHT ANGLE, RED/GREEN KINGBRIGHT W42WUM/EGW 4
Reference
Designator
Description Vendor Vendor Part
Number
Note
Q100 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q101 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q102 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q103 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q104 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q105 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q106 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q107 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q109 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q110 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q111 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q112 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q113 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
