Bose ControlSpace ESP-88C - Electrical Part Lists

19
ELECTRICAL PART LIST
Resistors
ESP-88C and ESP-00 Chassis Motherboard PCB Assembly
Reference
Designator
Description Vendor Part Number Vendor Name Note
R100 10k RK73H1JTD10KF KOA 4
R101 1k RK73H1JTD1KF KOA 4
R102 0 Ohm RK73Z1JTD 0RJ KOA 4
R103 0 Ohm RK73Z1JTD 0RJ KOA 4
R104 0 Ohm RK73Z1JTD 0RJ KOA 4
R105 0 Ohm RK73Z1JTD 0RJ KOA 4
R106 10k RK73H1JTD10KF KOA 4
R107 10k RK73H1JTD10KF KOA 4
R108 10k RK73H1JTD10KF KOA 4
R109 10k RK73H1JTD10KF KOA 4
R110 10k RK73H1JTD10KF KOA 4
R111 0 Ohm RK73Z1JTD 0RJ KOA 4
R112 0 Ohm RK73Z1JTD 0RJ KOA 4
R113 0 Ohm RK73Z1JTD 0RJ KOA 4
R114 0 Ohm RK73Z1JTD 0RJ KOA 4
R115 68 Ohm RK73H1JTD68RF KOA 4
R116 68 Ohm RK73H1JTD68RF KOA 4
R117 68 Ohm RK73H1JTD68RF KOA 4
R118 0 Ohm RK73Z1JTD 0RJ KOA 4
R119 0 Ohm RK73Z1JTD 0RJ KOA 4
R120 0 Ohm RK73Z1JTD 0RJ KOA 4
R200 220k RK73H1JTD220kF KOA 4
R201 8.2k RK73H1JTD8.2KF KOA 4
R202 12k RK73H1JTD12KF KOA 4
R203 OPEN NOT USED NOT USED 4
R204 10k RK73H1JTD10KF KOA 4
R205 2.2k RK73H1JTD2.2KF KOA 4
R211 1k RK73H1JTD1KF KOA 4
R213 1k RK73H1JTD1KF KOA 4
R214 10k RK73H1JTD10KF KOA 4
R215 10k RK73H1JTD10KF KOA 4
R216 10k RK73H1JTD10KF KOA 4
R220 2.2k RK73H1JTD2.2KF KOA 4
R221 2.2k RK73H1JTD2.2KF KOA 4
R222 33 Ohm RK73H1JTD33RF KOA 4
R223 33 Ohm RK73H1JTD33RF KOA 4
R236 220k RK73H1JTD220kF KOA 4
R237 OPEN NOT USED NOT USED 4
R238 10k RK73H1JTD10KF KOA 4
R239 2.2k RK73H1JTD2.2KF KOA 4
R240 8.2k RK73H1JTD8.2KF KOA 4
R241 12k RK73H1JTD12KF KOA 4
R300 68 Ohm RK73H1JTD68RF KOA 4
R301 68 Ohm RK73H1JTD68RF KOA 4
R302 68 Ohm RK73H1JTD68RF KOA 4
R303 33 Ohm RK73H1JTD33RF KOA 4
