Bose ControlSpace ESP-88C - Chassis 4 X4 PCB Assembly

26
ELECTRICAL PART LIST
Diodes
Transistors
Integrated Circuits
Miscellaneous
ESP-88C and ESP-00 Chassis Motherboard PCB Assembly
Reference
Designator
Description Vendor Part Number Vendor Name Note
D201 OPEN NOT USED NOT USED 4
D202 1SR154-400 1SR154-400 RHOM 4
D207 1SR154-400 1SR154-400 RHOM 4
D208 1SR154-400 1SR154-400 RHOM 4
Reference
Designator
Description Vendor Part Number Vendor Name Note
Q100 DTA114EKA DTA114EKA RHOM 4
Q101 OPEN NOT USED NOT USED 4
Q202 2SB1122S 2SB1122S SANYO 4
Q203 DTC114EKA DTC114EKA RHOM 4
Q205 DTC114EKA DTC114EKA RHOM 4
Q211 DTA114EKA DTA114EKA RHOM 4
Reference
Designator
Description Vendor Part Number Vendor Name Note
M100 74VHC138A TC74VHC138FT TOSHIBA 4
M104 74VHC138A TC74VHC138FT TOSHIBA 4
M200 uPC2933T uPC2933T NEC 4
Reference
Designator
Description Vendor Part Number Vendor Name Note
CN100 87BMN-030SF 87BMN-030S KEL 4
CN101 87BMN-030SF 87BMN-030S KEL 4
CN102 87BMN-030SF 87BMN-030S KEL 4
CN103 87BMN-030SF 87BMN-030S KEL 4
CN104 87BMN-030SF 87BMN-030S KEL 4
CN105 87BMN-030SF 87BMN-030S KEL 4
CN106 87BMN-030SF 87BMN-030S KEL 4
CN107 87BMN-030SF 87BMN-030S KEL 4
CN108 87BMN100S 87BMN-100S KEL 4
CN200 B6P-VH B6P-VH NICHIATSU 4
CN202 B8B-XH B8B-XH NICHIATSU 4
CN203 B8B-XH B8B-XH NICHIATSU 4
CN204 B8B-XH B8B-XH NICHIATSU 4
CN205 B3B-XH B3B-XH NICHIATSU 4
