Bose ControlSpace ESP-88C - Digital Signal Processor (DSP) PCB Assembly

43
ELECTRICAL PART LIST
Transistors
ESP-88C Chassis 4x4 Series II PCB Assembly
Diodes
Reference
Designator
Description Vendor Part Number Vendor Name Note
D500 1SS396 1SS396 TOSHIBA 4
D501 1SS396 1SS396 TOSHIBA 4
D502 1SS396 1SS396 TOSHIBA 4
D503 1SS396 1SS396 TOSHIBA 4
D504 1SS396 1SS396 TOSHIBA 4
D505 1SS396 1SS396 TOSHIBA 4
D506 1SS396 1SS396 TOSHIBA 4
D507 1SS396 1SS396 TOSHIBA 4
D600 DAN217 DAN217 RHOM 4
D601 DAN217 DAN217 RHOM 4
D602 DAN217 DAN217 RHOM 4
D603 DAN217 DAN217 RHOM 4
D604 DAN217 DAN217 RHOM 4
D605 DAN217 DAN217 RHOM 4
D606 DAN217 DAN217 RHOM 4
D607 DAN217 DAN217 RHOM 4
D608 OPEN NOT USED NOT USED 4
D700 1SR154-400 1SR154-400 RHOM 4
D701 1SR154-400 1SR154-400 RHOM 4
D702 OPEN NOT USED NOT USED 4
D703 OPEN NOT USED NOT USED 4
D704 OPEN NOT USED NOT USED 4
D705 OPEN NOT USED NOT USED 4
Reference
Designator
Description Vendor Part Number Vendor Name Note
Q100 DTC114EKA DTC114EKA RHOM 4
Q101 DTC114EKA DTC114EKA RHOM 4
Q102 DTA114EKA DTA114EKA RHOM 4
Q103 DTA114EKA DTA114EKA RHOM 4
Q200 DTC114EKA DTC114EKA RHOM 4
Q201 DTC114EKA DTC114EKA RHOM 4
Q202 DTA114EKA DTA114EKA RHOM 4
Q203 DTA114EKA DTA114EKA RHOM 4
Q300 DTC114EKA DTC114EKA RHOM 4
Q301 DTA114EKA DTA114EKA RHOM 4
Q302 DTC114EKA DTC114EKA RHOM 4
Q303 2SC3326 2SC3326 TOSHIBA 4
Q304 2SC3326 2SC3326 TOSHIBA 4
Q305 2SC3326 2SC3326 TOSHIBA 4
Q306 2SC3326 2SC3326 TOSHIBA 4
Q307 DTC114EKA DTC114EKA RHOM 4
Q308 DTA114EKA DTA114EKA RHOM 4
Q309 DTC114EKA DTC114EKA RHOM 4
Q400 DTC114EKA DTC114EKA RHOM 4
Q401 DTA114EKA DTA114EKA RHOM 4
