44
ELECTRICAL PART LIST
Integrated Circuits
ESP-88C Chassis 4x4 Series II PCB Assembly
Transistors (continued)
Reference
Designator
Description Vendor Part Number Vendor Name Note
Q402 DTC114EKA DTC114EKA RHOM 4
Q403 2SC3326 2SC3326 TOSHIBA 4
Q404 2SC3326 2SC3326 TOSHIBA 4
Q405 2SC3326 2SC3326 TOSHIBA 4
Q406 2SC3326 2SC3326 TOSHIBA 4
Q407 DTC114EKA DTC114EKA RHOM 4
Q408 DTA114EKA DTA114EKA RHOM 4
Q409 DTC114EKA DTC114EKA RHOM 4
Q700 DTC114EKA DTC114EKA RHOM 4
Q701 DTC114EKA DTC114EKA RHOM 4
Q702 DTC114EKA DTC114EKA RHOM 4
Q703 DTC114EKA DTC114EKA RHOM 4
Q704 DTC114EKA DTC114EKA RHOM 4
Q705 DTC114EKA DTC114EKA RHOM 4
Q706 DTC114EKA DTC114EKA RHOM 4
Reference
Designator
Description Vendor Part Number Vendor Name Note
M100 TC9164CFG TC9164CFG TOSHIBA 4
M101 NJM4580E NJM4580ETE2(JRC) JRC 4
M102 NJM4580E NJM4580ETE2(JRC) JRC 4
M103 NJM4580E NJM4580ETE2(JRC) JRC 4
M104 NJM4580E NJM4580ETE2(JRC) JRC 4
M200 TC9164CFG TC9164CFG TOSHIBA 4
M201 NJM4580E NJM4580ETE2(JRC) JRC 4
M202 NJM4580E NJM4580ETE2(JRC) JRC 4
M203 NJM4580E NJM4580ETE2(JRC) JRC 4
M204 NJM4580E NJM4580ETE2(JRC) JRC 4
M300 NJM4580E NJM4580ETE2(JRC) JRC 4
M301 NJM4580E NJM4580ETE2(JRC) JRC 4
M302 NJM4580E NJM4580ETE2(JRC) JRC 4
M303 NJM4580E NJM4580ETE2(JRC) JRC 4
M400 NJM4580E NJM4580ETE2(JRC) JRC 4
M401 NJM4580E NJM4580ETE2(JRC) JRC 4
M402 NJM4580E NJM4580ETE2(JRC) JRC 4
M403 NJM4580E NJM4580ETE2(JRC) JRC 4
M500 CS5361-KZ CS5361-KZ CIRRUS 4
M501 CS5361-KZ CS5361-KZ CIRRUS 4
M550 CS4392-KZ CS4392-KZ CIRRUS 4
M551 CS4392-KZ CS4392-KZ CIRRUS 4
M700 74VHC541 TC74VHC541FT TOSHIBA 4
M701 74VHC541 TC74VHC541FT TOSHIBA 4
M702 74AC273 TC74AC273FT TOSHIBA 4
M703 S-80947CNMC-G9H S-80947CNMC-G9H SEIKO 4
M704 TA48033F uPC2933T TOSHIBA 4
M705 TA7805F uPC2905AT TOSHIBA 4
M707 74AC273 TC74AC273FT TOSHIBA 4
