Bose ControlSpace ESP-88C - Main Part List, Control Space ESP-88 Chassis (See Figure 4)

15
MAIN PART LIST
ControlSpace
®
ESP-88C/ESP-00 Chassis (see Figure 4)
Item
Number
Description Qty. Part Number
Note
1 TOP COVER 1 278505-001
2 M3x4 SCREW, MSF, MS-BK
(FOR CHASSIS/COVER)
4 - 4
3 M3x4 SCREW, SI, MSB, MS-BK 62 - 4
4 GIO REAR PANEL, SECC-T1, T=1.0MM 1 278516-001
5 PANEL, REAR, BLANK, SECC-T1 T=1.0MM 5 278518-001
6 DSP REAR PANEL, SECC-T1, T=1.0MM 1 278515-001
7 4CH REAR PANEL (LINE OUTPUT) SECC-T1
T=1.0MM
2 278512-003
8 4CH REAR PANEL (MIC/LINE INPUT) SECC-T1
T=1.0MM
2 278512-002
9 4x4 LINE OUTPUT PCB ASSY
(PART OF ITEM 10 BELOW)
2 -
10 4X4 MIC/LINE SERIES II I/O PCB 2 041915 2
11 PCB FIXED STICK, ABOVE 2 278503-001
12 MOTHERBOARD PCB ASSY 1 318934-001S 2
13 M3x6 SCREW, MSB, M3x6mm, MS-BK 5 - 4
14 INTERNAL TOOTH WASHER,
OD 6.4xID3xT0.45MM
7 - 4
15 LED LENS, PMMA, MF001 9 278522-001
16 FRONT ENDCAP, RIGHT, PC/ABS, C2950
(M3x3 NUT)
1 278521-002
17 DOOR, ALUMINUM 1 278520-001
18 FRONT PANEL, ALUM, FIXED 1 278519-001
19 FRONT ENDCAP, MID, PC/ABS, C2950
(M3x2 NUT)
1 278521-003
20 FRONT ENDCAP, LEFT, PC/ABS, C2950
(M3x3 NUT)
1 278521-001
21 FRONT PANEL, SECC-T1 1 278507-001
22 CHASSIS 1 278506-001
23 PCB FIXED STICK, BELOW 1 278504-001
24 SCREW, US, MSF, 4#-40x0.236, MS, BLACK 4 - 4
25 LED PCB ASSEMBLY (PART OF MIC/LINE
IN/OUT MAIN PCB)
2 - 2
26 POWER SUPPLY, ASTEC 1 318933-001S 3
27 M4x12 SCREW, SI, MSB, MS-BK (FOR FAN) 4 - 4
28 DC FAN, +5VDC, 60MM, F6010AP-05LCW 1 295621 3
29 M4x3 HEX NUT W/NYLON INSERT, SI, SS 4 - 4
30 DSP PCB ASSEMBLY 1 275794 2
31 GPIO PCB ASSEMBLY 1 041768 2
32 STAY, SECC-T1, T=1.0MM 1 278508-001
- DSP EXPANSION CARD - 041769
- 8-CH DIGITAL IN EXP PCB - 041765
- 8-CH DIGITAL OUT EXP PCB - 041766
- 4-CH ANALOG IN EXP PCB
(EDR Line Level Input Card)
- 041764
- 4-CH ANALOG OUT EXP PCB
(EDR Line Level Output Card)
- 041763
