ELECTRICAL PART LIST
Miscellaneous
ESP-88C Chassis 4x4 Series II PCB Assembly
Reference
Designator
Description Vendor Part Number Vendor Name Note
CN600 B9B-XH B9B-XH NICHIATSU 4
CN601 2EHDRC-03P(GRN) 2EHDRC-03P(GRN) DINKL 4
CN602 2EHDRC-03P(GRN) 2EHDRC-03P(GRN) DINKL 4
CN603 2EHDRC-03P(GRN) 2EHDRC-03P(GRN) DINKL 4
CN604 2EHDRC-03P(GRN) 2EHDRC-03P(GRN) DINKL 4
CN700 87BFN-030R 87BFN-030R KEL 4
CN701 OPEN NOT USED NOT USED 4
CN702 OPEN NOT USED NOT USED 4
CN703 OPEN NOT USED NOT USED 4
CN704 OPEN NOT USED NOT USED 4
FG600 OG-363040 OG-363040 KITAGAWA
INDUSTRIES
4
FG601 OG-363040 OG-363040 KITAGAWA
INDUSTRIES
4
FG602 OG-363040 OG-363040 KITAGAWA
INDUSTRIES
4
P700 OPEN NOT USED NOT USED 4
XTAL700 10.000 MHZ HC49/S310.000MHZ KYISHYUDENTSU 4
