Bose ControlSpace ESP-88C - Page 28

28
ELECTRICAL PART LIST
Resistors (continued)
ESP-88C Chassis 4x4 Series II PCB Assembly
Reference
Designator
Description Vendor Part Number Vendor Name Note
R147 12k RK73H1JTD12KF KOA 4
R148 6.8k RK73H1JTD6.8KF KOA 4
R149 12k RK73H1JTD12KF KOA 4
R150 12k RK73H1JTD12KF KOA 4
R151 6.8k RK73H1JTD6.8KF KOA 4
R152 6.8k RK73H1JTD6.8KF KOA 4
R153 12k RK73H1JTD12KF KOA 4
R156 12k RK73H1JTD12KF KOA 4
R157 6.8k RK73H1JTD6.8KF KOA 4
R158 6.8k RK73H1JTD6.8KF KOA 4
R159 12k RK73H1JTD12KF KOA 4
R160 12k RK73H1JTD12KF KOA 4
R161 6.8k RK73H1JTD6.8KF KOA 4
R162 12k RK73H1JTD12KF KOA 4
R163 6.8k RK73H1JTD6.8KF KOA 4
R164 10k RK73H1JTD10KF KOA 4
R165 10k RK73H1JTD10KF KOA 4
R166 39k RK73H1JTD39KF KOA 4
R167 39k RK73H1JTD39KF KOA 4
R168 39k RK73H1JTD39KF KOA 4
R169 4.7k RK73H1JTD4.7KF KOA 4
R170 1.8k RK73H1JTD1.8KF KOA 4
R171 1.2k RK73H1JTD1.2KF KOA 4
R172 4.7k RK73H1JTD4.7KF KOA 4
R173 4.7k RK73H1JTD4.7KF KOA 4
R174 1.8k RK73H1JTD1.8KF KOA 4
R175 1.2k RK73H1JTD1.2KF KOA 4
R176 4.7k RK73H1JTD4.7KF KOA 4
R200 100k RK73H1JTD100kF KOA 4
R201 100 Ohm RK73H1JTD100RF KOA 4
R202 100 Ohm RK73H1JTD100RF KOA 4
R203 100k RK73H1JTD100kF KOA 4
R204 OPEN NOT USED NOT USED 4
R205 6.8k RK73H1JTD6.8KF KOA 4
R206 6.8k RK73H1JTD6.8KF KOA 4
R207 OPEN NOT USED NOT USED 4
R208 6.8k RK73H1JTD6.8KF KOA 4
R209 6.8k RK73H1JTD6.8KF KOA 4
R210 1.3k RK73H1JTD1.3KF KOA 4
R211 OPEN NOT USED NOT USED 4
R212 5.1k RK73H1JTD5.1KF KOA 4
R213 OPEN NOT USED NOT USED 4
R214 OPEN NOT USED NOT USED 4
R215 82 Ohm RK73H1JTD82RF KOA 4
R216 OPEN NOT USED NOT USED 4
R217 68 Ohm RK73H1JTD68RF KOA 4
