ELECTRICAL PART LIST

ESP-88 General Input/Output (GIO) PCB Assembly

Capacitors

Reference

Designator

Description Vendor Vendor Part

Number

Note

C100 10uF, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4

C101 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4

C102 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4

C103 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4

C104 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4

C105 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4

C106 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4

C107 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4

C108 0.01uF, 0603, X7R, 50V, 55C, 10% Samsung CL10B103KBNC 4

C109 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C110 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C111 10uF, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4

C112 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C113 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C114 10uF, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4

C115 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C116 12pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C120JBNC 4

C117 12pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C120JBNC 4

C118 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C119 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C120 47uF, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4

C121 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C122 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C123 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C124 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C125 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C126 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C127 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C128 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C129 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C130 0.1uF, 0603, Y5V, 50V, -30C, 20% Samsung CL10F104ZBNC 4

C131 47pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C470JBNC 4

C132 47pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C470JBNC 4

C403 1000pF, CER, Y5P, 2KV, 55C,

10%

Panasonic ECKD3D102KBP 4
