Bose ControlSpace ESP-88C User Manual

56
ELECTRICAL PART LIST
ESP-88 General Input/Output (GIO) PCB Assembly
Integrated Circuits
Miscellaneous
Reference
Designator
Description Vendor Vendor Part
Number
Note
M100 VOLTAGE DETECTOR, TSOP-5 ONSEMI NCP303LSN30T1 4
M100 VOLTAGE DETECTOR, SOT-23-5 SEIKO S-80930CNMC-G80-
T2
4
M101 REGULATOR, 3.3V, 1A, TO-252 NEC UPC2933T 4
M102 FLASH, MCU, 32K, LQFP64 RENASES HD64F3664FP 4
M451 TRANSCEIVER, PDIP-8 TI SN75176BP 4
Reference
Designator
Description Vendor Vendor Part
Number
Note
CN100 HEADER, RT ANG, 9 POS, P3.81 Dinkle ECH381R-09P 4
CN101 HEADER, RT ANG, 9 POS, P3.81 Dinkle ECH381R-09P 4
CN102 SHROUDED HEADER, TOP
ENTRY, 8 CKT, P=2.5
Neltron 2317SJ-08 4
CN400 JACK, MODULAR, TM5RJ2-88 HIROSE TM5RJ2-88 4
CN450 HEADER, RIGHT ANGLE,
P2.74MM, 9 PINS
Omron XM2C-0912-112 4
CN450 HEADER, RIGHT ANGLE,
P2.74MM, 9 PINS
WIESON 3170-09MANS4DW 4
CN451 HEADER, RIGHT ANGLE,
P5.08MM, 3 POLES, 2EHDRC-03P
DINKLE 2EHDRC-03P 4
XTAL300 32.768KHz, 20ppm, 12.5pF,
D3X8MM
Raltron R38-32.768-12.5 4
XTAL301 16.000MHz, 30ppm, 20pF, HC-
49/S
Raltron AS-16.000-20 4
XTAL400 20.000MHz, 30ppm, 20pF, HC-
49/S
Raltron AS-20.000-20 4
XTAL100 CRYSTAL, 10.000MHz, 30ppm,
20pF, HC-49/S
Raltron AS-10.000-20 4
BT450 COIN CELL, LITHIUM BATTERY
WITH SOLDERING TAB, BR2325
PANASONIC BR2325-1HCE 4
