ELECTRICAL PART LIST
Integrated Circuits
Miscellaneous
CC-64 Control Center
Reference
Designator
Description Vendor
Name
Vendor Part
Number
M100 QUAD 2-INPUT AND, TSSOP14 ON Semi
MC74VHC08DT
4
M101 CMOS, SRAM, TSOP44 Samsung
K6R1016C1D-TC10
4
M102 MCU, FLASH, UNPROG, FP-100B Hitachi
HD64F3069RF25
4
M200 HEX INVERTER, TSSOP14 ON Semi
MC74VHC04DT
4
M201 EEPROM, DIP8, ATMEL ATMEL
AT93C46-10PI-2.7
4
M202 ETHERNET CONT, PQFP-100 Realtek
RTL8019AS
4
M300 LED DISPLAY DRIVER, QSOP16 MAXIM
MAX6951CEE
4
M400 DECODER, TSSOP16 ONSEMI
MC74VHC138DT
4
M401 OCTAL BUFFER DRIVER, TSSOP20 ON Semi
MC74VHC541DT
4
M402 OCTAL BUFFER DRIVER, TSSOP20 ON Semi
MC74VHC541DT
4
M403 OCTAL D-TYPE F-F, TSSOP20 ON Semi
MC74VHC574DT
4
M404 IDENTITY COMP, TSSOP20 Fairchild
74ACT521MTC
4
M500 DC/DC CONVERTER, DIP-24 Cincon Elec
EC5A-12S05
4
M501 VOLTAGE DETECTOR, TSOP-5 ONSemi
NCP303LSN47T1
4
M501 VOLTAGE DETECTOR, SOT-23-5 Seiko
S80947CNMC-G9H-
T2
4
M503 OCTAL BUFFER DRIVER, TSSOP20 ON Semi
MC74VHC541DT
4
M504 OCTAL D-TYPE FLIP-FLIP,
TSSOP20
ON Semi
MC74VHC574DT
4
Reference
Designator
Description Vendor
Name
Vendor Part
Number
CN100 CONNECTOR, 6POLE, P2.5MM Neltron
2317SJ-06
4
CN200 MODULAR JACK, 7006-8P8C-M-01 Neltron
7006-8P8C-M-01
4
CN501 WIRE TO BOARD HEADER,
P5.08MM, 2POLE, 2EHDVC-02P
Dinkle
2EHDVC-02P
4
CN503 PCB SOCKET, DUAL ROW,
P2.54MM, 16POLE, H=7.1MM
Neltron
2214S-16G
4
E400 ENCODER, SW, 5P, 5V/10mA ALPS
EC11E15244EF
4
E401 ENCODER, SW, 5P, 5V/10mA ALPS
EC11E15244EF
4
E402 ENCODER, SW, 5P, 5V/10mA ALPS
EC11E15244EF
4
E403 ENCODER, SW, 5P, 5V/10mA ALPS
EC11E15244EF
4
E404 ENCODER, SW, 5P, 5V/10mA ALPS
EC11E15244EF
4
JP500 HEADER, P2.54MM, 3PIN, H=6.0MM Neltron
2211S-03G
4
JP501 HEADER, P2.54MM, 3PIN, H=6.0MM Neltron
2211S-03G
4
LCM HEADER, P2.54MM, 16PIN,
H=6.0MM
Neltron
2213S-16G
4
SW400
SW401
SW402
SW403
TACT SW, SMT, 12V/50mA, 160g,
H=5MM, TD-06XA
Wealth
Metal
TD-06XAX
4
XTAL100 20.000MHz +/-30ppm, 20pF, HC-49/S Raltron
AS-20.000-20
4
XTAL200 20.000MHz +/-30ppm, 20pF, HC-49/S Raltron
AS-20.000-20
4
/JP500 JUMPER, CAP, 2 PIN, 6MM Computime
22Z02-0611
4
/JP501 JUMPER, CAP, 2 PIN, 6MM Computime
22Z02-0611
4
/LED PCB FLAT CABLE, 18P, 2651, #26AWG,
L=39MM, GREY, UL&CSA
Computime
3618BA00396K0Z04
4
