89
5-3.Gain +24dB
ESP-88 Chassis Settings: Set all channel gains to = 24dB.
(Command on COM = ^BA{1/2}{L/R}24^C)
AMPL(1kHz)
ATS2 Settings
Test Limits
Noise
ATS2 Settings
Test Limits
Perform this test on channels 1 through 8.
5-3-1.Gain +30dB (Perform this test if using the 4x4 Series II card)
ESP-88 Chassis Settings: Set all channel gains to = 30dB.
(Command on COM = ^BA{1/2}{L/R}30^C)
AMPL(1kHz)
ATS2 Settings
Test Limits
TEST PROCEDURES
Item Setting
Frequency 1kHz
Amplitude -20.00dBu
B/W <10HZ / FS/2
Filter None
Item Upper limit Lower limit
Level +5.5dBu +2.5dBu
Item Setting
Frequency --
Amplitude Off
B/W 22HZ / 22KHz LPF
Filter “A” Weighting
Item Upper limit Lower limit
Level -77dBu -200dBu
Item Setting
Frequency 1kHz
Amplitude -20.00dBu
B/W <10HZ / FS/2
Filter None
Item Upper limit Lower limit
Level +5.5dBu +2.5dBu
