Front Panel User Interface
Front Panel Menu Structure Control Map
Front panel configuration is outlined in the following menu structure map.
Home Screen
Mono Stereo Mono HP+Bass Stereo HP+BassCustom Scenes Utility Menu
Preset Library
Preset Library Preset Library Preset LibrarySaved Scenes
Max Input Level Input Gain
Delay Output Gain User Lockout Factory Reset
18 dBu
6 dBu
0 dBu
InA
InB
InA xx.x dB
InB xx.x dB
Out1
Out2
Out3
Out4
Out1 xxx.x ms
Out2 xxx.x ms
Out3 xxx.x ms
Out4 xxx.x ms
Out1
Out2
Out3
Out4
Out1 xx.x dB
Out2 xx.x dB
Out3 xx.x dB
Out4 xx.x dB
Press > to Lock Press > to Set
Thursday, March 29, 12
Note: When navigating down from the Home Screen, the active Preset Category or Scene Category will display.
