Mixer Mode user interface application
Note: Output 1 gain can be configured as the Master Volume, controlling Output 1 and Output 2 gains simultaneously using the
MasterVol Linked menu option.
Stereo Select Mode user interface application
Dual Mono Select Mode user interface application
Adjusts the
volume of the
OUTPUT 1
audio mix
GAIN knobs
disabled with
user interface
use
Adjusts the
volume of the
OUTPUT 2
audio mix
Adjusts the
volume
Selects one
source (A) or
the other (B) in
the single zone
GAIN knobs
disabled with
user interface
use
Adjusts the
volume
Adjusts the
volume
Selects one
source (A) or
the other (B) in
Zone 1
Selects one
source (A) or
the other (B) in
Zone 2
GAIN knobs
disabled with
user interface
use
Figure 21. Mixer Mode with volume control user interfaces
Figure 22. Stereo Select Mode with volume control user interface.
Figure 23. Dual Mono Select Mode with volume control user interfaces
