Bose FreeSpace IZA 2120-LZ Installation And Operation Guide

Installation
pro.Bose.com
Installation Guide - 31
Two CC-1s
Connect two ganged CC-1 zone controllers to FreeSpace® amplifier models IZA 2120-HZ or ZA 2120-HZ.
DIP switch settings are the same when connecting to the ZA 2120-HZA.
RJ-45 (Main)
on CC-1 #1
Wiring with
Optional CAT 5
Daisy-Chain
Wiring if Using
Two Home Runs
to IZA 2120-HZ
RJ-45 (Chain)
on CC-1 #2
VOL #2
RJ
FreeSpace
IZA 2120-HZ
VOL #2
PWR #2
RJ-45 (Main)
on CC-1 #1
RJ-45 (Chain)
on CC-1 #2
FreeSpace
ZA 2120-HZ
Wiring with
Optional CAT 5
Daisy-Chain
Wiring if Using
Two Home Runs
to ZA 2120-HZ
VOL #2
PWR #2
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #1
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #2
