Bose FreeSpace IZA 250-LZ

32
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ Main PCB Assembly
Inductors
Reference
Designator
Description
V
endor Part
Number
Note
D303A FERRITE, BEAD, 26430000101, (FAI
R
-RITE) 1808-0670+0 4
D304C FERRITE, BEAD, 26430000101,
(
FAI
R
-RITE
)
1808-0670+0 4
L300 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L301 10MH, CHOKE-COMMON, MODE, 10MH, MIN, AC,
240V, 2A, AL
1806-4037+0000 4
L302 10MH, CHOKE-COMMON, MODE, 10MH, MIN, AC,
240V, 2A, AL
1806-4037+0000 4
L303 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L304 FERRITE, BEAD, INDUCTO
R
, BL01RN1A1F1J 1808-0680+0 4
L305 FERRITE, BEAD, INDUCTO
R
, BL01RN1A1F1J 1808-0680+0 4
L306 FERRITE, COIL, 22UH, 20%, BL19.2 1807-220M+9 4
L310 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L311 FERRITE, BEAD, INDUCTO
R
, BL01RN1A1F1J 1808-0680+0 4
L313 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L314 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L318 FERRITE, COIL, 22UH, 20%, BL19.2 1807-220M+9 4
L319 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L320 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L321 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L322 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L323 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L324 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L328 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4

Diodes
Reference
Designator
Description
V
endor Part
Number
Note
B300 DIODE, BRIDGE, 800V, 8
A
, GBU8K, RL 4840-9218+5 4
D300 DIODE, FAST, 800V, 2A, HER207, AT 480R-2070+2 4
D303 DIODE, ULTRA, 400V, 16A, MUR1640, TO-220AB,
RB
4801-6400+9 4
D304 DIODE, ULTRA, 400V, 16A, MUR1640, TO-220AB,
RB
4801-6400+9 4
D305 DIODE, 200V, 0.2A, BAV21W, SOD-123, SMD,
PANJIT
480V-21W0+3 4
D306 DIODE, LL4148, SM 4804-1480+3 4
D307 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190+3 4
D308 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190+3 4
D309 RECTIFIE
R
, UF4006-T, GI, AT 4840-8530+2 4
D311 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190+3 4
D312 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190+3 4
D314 DIODE, RECT, 200V, 2A, ER2D, SMB/DO-214A
A
,
SM
480E-R2D0+3 4
DZ300 DZ, 5W, 150V, 5%, AT 483B-1519+2 4
Z300 DZ, 5W, 10V, 5%, 1N5347B, AT, ON 483B-1005+2 4
Z301 DZ, 5W, 13V, 5%, AT 483B-1309+2 4
Z302 DZ, 5W, 13V, 5%, AT 483B-1309+2 4

