Bose FreeSpace IZA 250-LZ

51
Integrated Circuits
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ MIC PCB Assembly
Miscellaneous
FreeSpace IZA 190-HZ Output PCB Assembly
Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L1 FERRITE, COIL, 1.4M, 28%, BL15.2, RL, P5 1807-142T5 4

Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
P1 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
P2 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
P3 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
SP1 SOCKET, M, 3P, P5, 300V, 15A, GREEN 2113-3368 4

Reference
Designator
Description
V
endor Part
Number
Note
U102 NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890 4
U101 TL072CDR, DUAL, J-FET, INPUT, OP-
A
MP 3130-8020 4

Reference
Designator
Description
V
endor Part
Number
Note
Z142 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111 480M-1110 4
Z143 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111 480M-1110 4
J1 CONNECTOR, 9P, 2MM 2102-090S 4
J100 JACK, MIC, PHONE, COMBO, 11P, NCJ10FI-H-0,
NE
2113-3213 4
CON GND WIRE, GROUND, 1P, L=58, GREEN/YRL, RING 7012-9970 4

