Bose FreeSpace IZA 250-LZ

50
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ MIC PCB Assembly
Capacitors (continued)
Ferrite Beads
Diodes
Transistors
Reference
Designator
Description
V
endor Part
Number
Note
C123 220UF, CE, 6.3V, 20%, SM, 6.3X5.3, NOVER 157B-227MLJU 4
C125 220UF, CE, 6.3V, 20%, SM, 6.3X5.3, NOVER 157B-227MLJU 4
C127 220UF, CE, 6.3V, 20%, SM, 6.3X5.3, NOVER 157B-227MLJU 4
C115 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C116 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C162 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C163 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4

Reference
Designator
Description
V
endor Part
Number
Note
FB101 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878 4
FB102 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878 4
FB103 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878 4
FB104 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878 4
FB105 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878 4
FB106 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878 4
FB107 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878 4
FB108 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878 4

Reference
Designator
Description
V
endor Part
Number
Note
D101 BAV99, SOT23, PHILIPS 4840-8970 4
D104 DBAV99, SOT23, PHILIP
S
4840-8970 4

Reference
Designator
Description
V
endor Part
Number
Note
Q100 NPN, MMBT4401, SOT-23, HFE:, 20-300, SM 4854-4010 4
Q101 NPN, MMBT4401, SOT-23, HFE:, 20-300, SM 4854-4010 4
Q102 MMBT4403LT1G, SMD 4854-4030 4
Q103 MMBT4403LT1G, SMD 4854-4030 4
Q104 MMBT4403LT1G, SMD 4854-4030 4
Q105 MMBT4403LT1G, SMD 4854-4030 4
Q106 MMBT4403LT1G, SMD 4854-4030 4
Q107 MMBT4403LT1G, SMD 4854-4030 4
Q108 MMBT4403LT1G, SMD 4854-4030 4
Q109 MMBT4403LT1G, SMD 4854-4030 4

