Bose FreeSpace IZA 250-LZ

49
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ MIC PCB Assembly
Resistors
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
R145 0R, RMG, 1/16W, 1%, 0603 4723-000A 4
R155 0R, RMG, 1/16W, 1%, 0603 4723-000JR 4
R125 10R, RMG, 1/16W, 5%, 0603/1608 4723-100J 4
R127 10R, RMG, 1/16W, 5%, 0603/1608 4723-100J 4
R144 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R152 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R108 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R113 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R115 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R112 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103AR 4
R138 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103AR 4
R147 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103AR 4
R148 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A
R
4
R102 15R, RMG, 1/16W, 5%, 0603, HK, RESISTOR/SA 4723-150JR 4
R106 150R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-151AR 4
R107 150R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-151A
R
4
R109 150R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-151AR 4
R111 150R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-151AR 4
R135 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A 4
R158 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A 4
R114 2.2K, RMG, 1/16W, 5%, 0603, HK, RESISTOR/SA 4723-222JR 4
R153 2.2K, RMG, 1/16W, 5%, 0603, HK, RESISTOR/SA 4723-222JR 4
R124 4.99K, RMG, 1/16W, 1%, 0603 4723-4991 4
R126 4.99K, RMG, 1/16W, 1%, 0603 4723-4991 4
R128 4.99K, RMG, 1/16W, 1%, 0603 4723-4991 4
R132 4.99K, RMG, 1/16W, 1%, 0603 4723-4991 4
R105 9.76K, RMG, 1/16W, 1%, 0603 4723-9761 4

Reference
Designator
Description
V
endor Part
Number
Note
C130 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C134 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C150 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C151 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C138 1000PF, CC, 50V, 5%, 0603, X7R 150F-102JAC 4
C120 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C121 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C128 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C136 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C145 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C146 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C160 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C161 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C131 470PF, CC, 50V, 5%, 0603 150F-471JAC 4
C132 470PF, CC, 50V, 5%, 0603 150F-471JAC 4
C122 220UF, CE, 6.3V, 20%, SM, 6.3X5.3, NOVER 157B-227MLJU 4

