Bose FreeSpace IZA 250-LZ

48
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ 3.5mm Jack PCB Assembly
Integrated Circuits
Miscellaneous
FreeSpace IZA 190-HZ LED PCB Assembly
Resistors
Diodes
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
R116 300R, RMG, 1/16W, 5%, 0603 4723-301J+P 4
R118 300R, RMG, 1/16W, 5%, 0603 4723-301J+P 4

Reference
Designator
Description
V
endor Part
Number
Note
D315 LED, 3MM, RED 3700-2522+R 4
D313 LED, 3MM, BLUE, SP, SLR343BB, T 225419 ROHM 3700-2824+B 4

Reference
Designator
Description
V
endor Part
Number
Note
J108B CONN, 3
P
, ST.,WAFE
R
, P=2.0, COULOMB 2102-030S+003 4

Reference
Designator
Description
V
endor Part
Number
Note
U12 OP-AMP, SMD, 105C, BA4560RF, SOP8 3132-7011 4
U100 TL072CDR, DUAL, J-FET, INPUT, OP-AMP 3130-8020 4
U103 TL072CDR, DUAL, J-FET, INPUT, OP-AMP 3130-8020 4
U105 TL072CDR, DUAL, J-FET, INPUT, OP-AMP 3130-8020 4

Reference
Designator
Description
V
endor Part
Number
Note
CON GND WIRE, GROUND, 1P, L=58, GREEN/YRL, RING 7012-9970 4
J1A WIRE-CONN, 10P, P2.0, #26, UL1061, L=300, B 7013-1990 4
J2A WIRE-SHI, 8P, P2.0, #26, UL1, 061/2547, L=400 7013-2161 4
J9A1 WIRE-SHI, 12P, P2.0, #26, UL, 1061/2547, L130 7013-2150 4
J101 INLET, EARPHONE, 50V, 1A, 3.5MM 2113-3332 4
SW100 SWITCH, SLIDE, DPDT, 50V, 0.5A, L=14, META 5200-5013 4
VR100 VR, ROTARY, 10K/10CX1, 20%, V, L=30, 40TEETH 4751-223E 4
VR101 VR, ROTARY, B20KX1, 20%, C.C, V, L=30,
40TEETH
4751-227E 4
VR102 VR, ROTARY, B20KX1, 20%, C.C, V, L=30,
40TEETH
4751-227E 4
VR103 VR, ROTARY, B20KX1, 20%, V, L=15 4751-2280 4

