Bose FreeSpace IZA 250-LZ

47
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ 3.5mm Jack PCB Assembly
Capacitors (continued)
Inductors
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
C108 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C109 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C111 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C113 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C114 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103KAC 4
C117 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C119 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C129 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C133 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103KAC 4
C135 1000PF, CC, 50V, 5%, 0603, X7R 150F-102JAC 4
C137 0.1UF, CC, 50V, 5%, 0603 150F-104JAC 4
C139 0.1UF, CC, 50V, 5%, 0603 150F-104JAC 4
C140 1000PF, CC, 50V, 5%, 0603, X7R 150F-102JAC 4
C141 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103KAC 4
C147 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C148 0.1UF, CC, 50V, 5%, 0603 150F-104JAC 4
C149 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103KAC 4
C152 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C153 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ 4
C154 0.1UF, CC, 50V, 5%, 0603 150F-104JAC 4
C155 0.1UF, CC, 50V, 5%, 0603 150F-104JAC 4
C156 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C157 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C158 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C159 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C165 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C166 0.1UF, CC, 50V, 5%, 0603 150F-104JAC 4
C167 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4
C168 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101JAC 4

Reference
Designator
Description
V
endor Part
Number
Note
L100 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630 4

Reference
Designator
Description
V
endor Part
Number
Note
D10 BAV99, SOT23, PHILIPS 4840-8970 4
D102 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY 480T-54S0 4
D105 BAV99, SOT23, PHILIPS 4840-8970 4
D106 BAV99, SOT23, PHILIPS 4840-8970 4
D107 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY 480T-54S0 4
D109 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY 480T-54S0 4

