Bose FreeSpace IZA 250-LZ

83
Resistors
ELECTRICAL PART LIST
FreeSpace
®
IZA 250-LZ 3.5mm Jack PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R1 5.1K, RMG, 1/16W, 1%, 0603/1608 4723-512A 4
R2 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111 480M-1110 4
R28 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R159 24.3K, RMG, 1/10W, 1%, 0603 4720-2432 4
R161 24.3K, RMG, 1/10W, 1%, 0603 4720-2432 4
R120 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R122 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R131 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R134 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R140 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R141 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R150 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R151 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R156 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R154 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R121 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A
R
4
R130 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103AR 4
R149 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103AR 4
R160 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103AR 4
R162 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A
R
4
R163 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103AR 4
R164 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103AR 4
R165 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A
R
4
R166 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A
R
4
R103 1M, RMG, 1/16W, 1%, 0603 4723-105A 4
R129 1M, RMG, 1/16W, 1%, 0603 4723-105A 4
R137 12K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-123A
R
4
R139 12K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-123AR 4
R142 1R, RMG, 1/16W, 5%, 0603 4723-1R0J 4
R146 1R, RMG, 1/16W, 5%, 0603 4723-1R0J 4
R104 5.1K, RMG, 1/16W, 1%, 0603/1608 4723-512A 4
R119 5.1K, RMG, 1/16W, 1%, 0603/1608 4723-512A 4
R143 5.1K, RMG, 1/16W, 1%, 0603/1608 4723-512A 4
R133 820R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-821AR 4
R136 820R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-821A
R
4

