Bose FreeSpace IZA 250-LZ

63
Resistors
ELECTRICAL PART LIST
FreeSpace
®
ZA 190-HZ LED PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R114 0R RMG 1/16W 1% 0603 4723-000A 4
R116 4.7K RMG 1/16W 5% 0603 HK RESISTOR/SAM
S
4723-472JR 4

Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D313 LED, 3MM, BLUE, SP, SLR343BB, T, 225419,
ROHM
3700-2824 4

Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J109B WIRE-CONN, 2P, P2.0, #24, UL, 1007, L=300,
WH/BU
7013-2370 4

Inductors
FreeSpace ZA 190-HZ Output PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
L1 FERRITE, COIL, 1.4M, 28%, BL15.2, RL, P5 1807-142T5 4

Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
P1 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
P2 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
P3 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
SP1 SOCKET, M 3P, P5, 300V, 15A, GREEN 2113-3368 4

