ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ DSP PCB Assembly
Capacitors (continued)
Reference
Designator
Description
V
endo
r
Part
Number
Note
C28 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C29 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C30 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C31 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C32 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C33 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C34 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C35 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C36 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C37 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C38 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C39 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C40 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C41 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C42 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C43 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C44 4.7UF, CC, 6.3V, 10%, 0603 150B-475K+P-AC 4
C45 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C46 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C47 0.1U
F
, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C48 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C49 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C50 0.1U
F
, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C51 0.1U
F
, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C52 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C53 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C54 0.1U
F
, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C55 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C56 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C57 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C58 0.1U
F
, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C59 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C60 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C61 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C62 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C63 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C64 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C65 270PF, CC, 50V, , 10%, 0603, 1x2 150F-271K+P-AC 4
C66 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C67 270PF, CC, 50V, , 10%, 0603, 1x2 150F-271K+P-AC 4
C68 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C69 560PF, CC, 50V, 10%, 0603/1608, 1X2 150F-561K+
P
-AC 4
C70 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C71 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C72 270PF, CC, 50V, , 10%, 0603, 1x2 150F-271K+P-AC 4
C73 0.47UF, CC, 10V, 10%, 0603, 332134745R1, RS 150C-474K+P-AC 4
C74 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4

