Bose FreeSpace IZA 250-LZ

42
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ Rear Panel I/O PCB Assembly
Resistors (continued)
Reference
Designator
Description
V
endo
r
Part
Number
Note
R243 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R244 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R245 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R246 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P 4
R247 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R248 3K, RMG, 1/16W, 1%, 0603 4723-302A+P 4
R249 27K, RMG, 1/16W, 1%, 0603/1608 4723-273A+P 4
R250 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R251 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+
P
4
R252 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R253 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P 4
R254 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P 4
R255 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R256 47K, RMG, 1/16W, 1%, 0603, HK, RESISTOR 4723-473A+P-R 4
R257 47K, RMG, 1/16W, 1%, 0603, HK, RESISTOR 4723-473A+P-R 4
R258 27K, RMG, 1/16W, 1%, 0603/1608 4723-273A+
P
4
R259 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R260 2.2K, RMG, 1/16W, 5%, 0603, HK, RESISTOR/SA 4723-222J+P-R 4
R262 15R, RMG, 1/16W, 5%, 0603, HK, RESISTOR/SA 4723-150J+P-R 4
R263 10R, RMG, 1/16W, 5%, 0603, HK, RESISTOR/S 4723-100J+
P
-
R
4
R264 10R, RMG, 1/16W, 5%, 0603, HK, RESISTOR/S 4723-100J+P-R 4
R265 150R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-151A+P-R 4
R266 150R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-151A+P-
R
4
R267 150R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-151A+P-
R
4
R268 150R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-151A+P-R 4
R269 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P 4
R270 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4

Capacitors
Reference
Designator
Description
V
endo
r
Part
Number
Note
C172 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C200 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C201 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C202 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C203 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C204 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C205 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C206 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C208 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C209 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C210 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C211 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C212 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C213 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C214 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C215 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+
P
-AC 4

