Bose FreeSpace IZA 250-LZ

54
Capacitors
ELECTRICAL PART LIST
FreeSpace
®
ZA 190-HZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C300 3300P
F
, CC, 1000V, 10%, RLT, 10X4, X7R, 125C 150N-332K+K-SG 4
C301 470UF, CE, 250V, 20%, RL, 30X30, 105C 157R-477M+5-$$T 4
C302 470UF, CE, 250V, 20%, RL, 30X30, 105C 157R-477M+5-$$T 4
C303 3300PF, CC, 1000V, 10%, RLT, 10X4, X7R, 125C 150N-332K+K-SG 4
C304 330PF, CC, 1000V, 10%, RLT, Y5P, 5.5X3.5 150N-331K+K-J
F
4
C305 47UF, CE, 10V, 20%, RLT, 5X11, 105C 157C-476M+K-IUT 4
C306 4.7UF, CE, 63V, 20%, RLT, 5X11, LOW ESR, 105C 157I-475M+K-IURT 4
C308 0.015UF, CC, 630V, 10%, 1206, , X7R 150M-153K+6-CF 4
C309 100UF, CE, 25V, 20%, RLT, 6.3X11, 105C, LOW
ESR
157E-107M+K-
LURT
4
C311 100UF, D, CAP-E, CE, 35V, 20%, RLT, 6.3X11,
105C, LOW ESR
157Q-107M+K-
LUTR
4
C312 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C313 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C314 47UF, CE, 25V, 20%, RLT, P5.0, 5X11, LOW ESR 157E-476M+K-IUR 4
C315 47UF, CE, 25V, 20%, RLT, P5.0, 5X11, LOW ESR 157E-476M+K-IUR 4
C316 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C317 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C318 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C319 10UF, CE, 50V, 20%, RLT, 5X11, 105C, RX,
NOVER
157F-106M+K-
IUTU
4
C320 0.1U
F
, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C321 0.1U
F
, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C322 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C323 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C324 0.68UF, CM, 100V, 5%, RBT, 7.2X11X6,
METALLIZED
153H-684J+V-NUM 4
C325 1000P
F
, CC, 1000V, 10%, RLT, 6X3, 125C, X7R 1511-102K+K-0N 4
C326 1000P
F
, CC, 1000V, 10%, RLT, 6X3, 125C, X7R 1511-102K+K-0N 4
C327 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C328 1000UF, CE, 16V, RLT, 10X16, R, E3, ELNA 157D-108M+K-S5E 4
C329 470UF, CE, 35V, 20%, RLT, 10X20, 105C, LOW
ESR
157Q-477M+K-
S9RT
4
C330 1000UF, CE, 35V, 20%, RLT, 12.5X25, 105C, LOW
ESR
157Q-108M+K-
X&TR
4
C331 0.015UF, CC, 50V, 10%, 0603 150F-153K+P-AC 4
C332 0.015UF, CC, 50V, 10%, 0603 150F-153K+P-AC 4
C333 47UF, CE, 100V, 20%, RLT10X16, LOW ESR 105C,
WB, SAMWHA
157H-476M+K-
S5RT
4
C334 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C335 100UF, CE, 35V, 20%, RLT, 6.3X11, 105C, LOW
ESR
157Q-107M+K-
LUTR
4
C336 1000UF, CE, 16V, RLT, 10X16, R, E3, ELNA 157D-108M+K-S5E 4
C337 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C338 0.1U
F
, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C339 470UF, CE, 35V, 20%, RLT, 10X20, 105C, LOW
ESR
157Q-477M+K-
S9RT
4

