Bose FreeSpace IZA 250-LZ

76
Capacitors (continued)
ELECTRICAL PART LIST
FreeSpace
®
IZA 250-LZ DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C83 33PF, CC, 50V, 5%, 0603/1608, , 1X2 150F-330J+P-AC 4
C84 33PF, CC, 50V, 5%, 0603/1608, , 1X2 150F-330J+P-AC 4
C85 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C86 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C87 0.1U
F
, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C88 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C89 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C90 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C91 0.1U
F
, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C92 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C93 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C94 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C95 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C96 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C97 22pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-220J+P-AC 4
C98 4.7U
F
, CC, 10V, 10%, 0805, X7
R
150C-475K+J-BD 4
C99 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C118 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C124 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C126 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
CAP1 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
CAP2 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
CAP3 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
CAP4 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
CAP5 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
CAP6 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
CAP7 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
CAP8 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4

Reference
Designator
Description
V
endor Part
Number
Note
L1 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630+0 4
L2 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630+0 4
L3 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630+0 4
L4 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630+0 4
L5 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L6 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L7 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L8 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L9 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L10 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L11 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L12 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L13 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L14 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4
L15 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0 4

Inductors
